High efficiency and ultra-high detail is a unique point of PRINCE, benefiting from red and blue laser working modes. It is easy to scan large plane even small coin, widely applied to industrial design, reverse engineering, quality control, quality inspection, culture relic 3D digital,3D film,3D game VR/AR， etc.
Tech Specs
| Type |
PRINCE775 |
| Mode |
Standard mode R |
Hyperfine mode B |
| Weight |
0.95kg |
| Dimensions |
315*165*105mm |
| Laser source |
7 red laser crosses
(+1 extra red laser) |
5 blue parallel laser lines |
| Scan deep hole |
Support |
| Hyperfine scan |
Support |
| Scan rate |
480,000 measures/s |
320,000 measures/s |
| Camera frame rate |
60fps |
120fps |
| Laser class |
CLASSⅡ (eye-safe) |
| Resolution |
0.05mm |
0.02mm |
| Accuracy |
Up to 0.03mm |
| Volumetric accuracy 1 |
0.02mm+0.06mm/m |
0.01mm+0.06mm/m |
Volumetric accuracy 2
（with MSCAN） |
0.02mm+0.025mm/m |
0.01mm+0.025mm/m |
| Stand-off distance |
300mm |
150mm |
| Depth of field |
250mm |
100mm |
| Effective work range |
200mm~450mm |
100mm~200mm |
| Output formats |
.ply、.xyz、.dae、.fbx、.ma、.obj、.asc、.stl or customized |
| Work temperature |
-10~40℃ |
| Interface mode |
Gigabit Lan |
| Patents |
CN204854633U, WO2017028600, CN105068384, WO2017020648, CN204854633U, CN105049664, CN204902785U, CN104501740 CN204944431U, WO2017024869, CN204963812U, CN106403845, WO2018049843, CN106500627, WO2018072434, CN106500628, WO2018072433, CN206132003U, US10309770B2 |
